標稱電壓(V) Nominal voltage(V)	3.2	3.2	3.2
標稱容量(Ah) Nominal capacity(Ah)	314	310	240
交流內阻(mΩ) Ac internal resistance (mΩ)	≤0.2	≤0.2	≤0.3
比能量(Wh/kg) Specific energy (Wh/kg)	≥180	≥180	≥180
最大持續/脈沖 充電倍率(C) Maximum continuous/pulse charging rate(C)	1C/2C	1C/2C	1C/1.2C
最大持續/脈沖 放電倍率(C) Maximum continuous/pulse discharge rate(C)	1C/2C	1C/2C	1.1C/1.3C
電芯尺寸 高x寬x厚 Cell Dimension (mm) HxWxD	207x174x72	207x174x72	207x174x54
循環壽命 周 (充/放) Cycle life (charge / discharge)	≥6000 (0.5P/0.5P)	≥6000 (0.5P/0.5P)	≥4000 (0.5C/1C)
重量 Weight(kg)	5.6±0.1	5.55±0.1	4.23±0.05
認證 Cetification	RoHS法規 / REACH法規 / MSDS / UN38.3 / 海運 / UL1973 / IEC 62619 RoHS regulations / REACH Regulations / MSDS / UN38.3 / Marine / UL1973 / IEC 62619	RoHS法規 / REACH法規 / MSDS / UN38.3 / 海運 / UL1973 / IEC 62619 / GB36276 / UL9540A RoHS regulations / REACH Regulations / MSDS / UN38.3 / Marine / UL1973 / IEC 62619 / GB36276 / UL9540A	RoHS法規 / REACH法規 / MSDS / UN38.3 / 海運 / GB38031 / GBT31484 / GBT31486 RoHS regulations / REACH Regulations / MSDS / UN38.3 / Marine / GB38031 / GBT31484 / GBT31486
連接方式 Connection method	鋁連接片激光焊接 Laser welding of aluminum busbar	鋁連接片激光焊接 Laser welding of aluminum busbar	鋁連接片激光焊接 Laser welding of aluminum busbar
